Galvanized Iron Wire Mesh Retaining Wall For Riverbank Protection And Soil Erosion Prevention

Large Image : Galvanized Iron Wire Mesh Retaining Wall For Riverbank Protection And Soil Erosion Prevention

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	CE, ISO, COC,BESC
Model Number:	KNG01

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	USD 12-17
Packaging Details:	pallet or bundle
Delivery Time:	7
Payment Terms:	L/C,Western Union,MoneyGram,T/T
Supply Ability:	1 40-foot high containers in 7 days

Contact Now Chat Now

Detailed Product Description

Material:	Galvanized Iron Wire,Low-Carbon Iron Wire,pvc Wire, Galfan Wire	Hole Shape:	Hexagonal, Double Twist
Wire Gauge:	2.4mm, 2.5mm, 2.7mm, 2.8mm, 3.05mm	Application:	Gabions,Cages,slope Protection,Fence Mesh,Construction Wire Mesh
Type:	Hexagonal Wire Mesh, Double Twist	Aperture:	80100mm,100120mm,60*80mm,etc,
Surface Treatment:	Hot Dipped Galvanized, PVCcoated, Galvanized+PVC Coated	Product Name:	Gabion Box, Gabion Box Wire Mesh,Gabion Basket,Hot Sale 2x1x1m PVC Coated Heavy Duty Gabion
Color:	Green,black,	Packing:	Pallet,Bundle
Usage:	Flood Control Retaining Wall, Protection,	Sample:	Available
Size:	2m1m1m,1x1x0.5m,411m,511,Customized,	Feature:	Easily Assembled,less Transport Freight,Strong And Durable, Simple Installation
Width:	2' -2m,0.914m~1.83m,0.5-2m,1M	Zinc Coated:	40-60g,60g-80g,270g,245g, Etc,
Highlight:	galvanized wire mesh retaining wall , galvanized wire rock retaining wall , riverbank wire mesh retaining wall

Galvanized Iron Wire Mesh Retaining Wall For Riverbank Protection And Soil Erosion Prevention

Galvanized Iron Wire Mesh Eco-Friendly Gabion Box Retaining Wall provides effective solutions for riverbank protection and soil erosion prevention. These structures stabilize riverbanks, prevent soil loss, and reduce water flow impact while promoting natural vegetation growth. Ideal for long-term erosion control, flood protection, and enhancing river ecosystem sustainability.

Standard Gabion Basket Sizes

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	1	0	1
2	1	1	1	2
3	1	1	2	3
4	1	1	3	4
5	1	1	4	5
6	1	1	5	6

Other sizes available for customization

Standard Gabion Mattress Sizes

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	0.3/0.5	0	0.3/0.5
2	1	0.3/0.5	1	0.6/1
3	1	0.3/0.5	2	0.9/1.5
4	1	0.3/0.5	3	1.2/2
5	2	0.3/0.5	4	3/5
6	2	0.3/0.5	5	3.6/6

Other sizes available for customization

Applications

Erosion Control: Stabilizes slopes and riverbanks while allowing proper water drainage
Retaining Walls: Secures hillside soil with natural aesthetic appeal for landscapes
Flood Protection: Forms durable barriers to divert water flow and protect infrastructure
Coastal Defense: Stabilizes shorelines against wave action and erosion
Road Embankments: Reinforces transportation routes by preventing landslides
Bridge Construction: Strengthens abutments and foundations for structural integrity

Technical Specifications

Parameter	Description	Typical Value / Range
Material	Base construction material	HDP/Galvanized Wire, PVC Wire
Coating	Surface treatment	Galvanized, HDP Galvanized, PVC Coated
Wire Diameter	Wire thickness	Mesh Wire: 2.0~3.05mm, Selvage Wire: 2.4~4.0mm, Tie Wire: 2.0~2.4mm
Mesh Opening Size	Opening between wires	60×80mm, 80×100mm, 100×120mm, 120×150mm
Overall Dimensions	Standard sizes	Gabion Roll Width: 1~4m, Gabion Basket: 1×1×1m to 6×1×1m
Lifespan	Service life expectancy	6~20 years (environment dependent)
