Hexagonal Gabion Cage Wire Rock Retaining Wall Flood Control Erosion Protection

Large Image : Hexagonal Gabion Cage Wire Rock Retaining Wall Flood Control Erosion Protection

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	gabion retaining wall

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 12-17
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 pc per day

Contact Now Chat Now

Detailed Product Description

Features:	Flexible, Easy To Assemble, Strong And Durable	Wire Diameter:	2.0-4.0 Mm
Filling Material:	Stones Or Rocks	Mesh Type:	Double Twisted Hexagonal
Zinc Coating:	240-300 G/m2	Size:	2x1x1 M
Application:	Erosion Control, Retaining Walls, Landscaping	Surface Treatment:	Hot-dipped Galvanized
Product Name:	Retaining Walls Hexagonal Gabion Cage River Bank Flood Control Erosion Protection Galvanized CE ISO	Key Words:	Gabion Retaining Wall
Highlight:	Hexagonal Gabion Cage Flood Control , river bank wire rock retaining wall , Erosion Protection Wire Rock Retaining Wall

Hexagonal Gabion Cage Wire Rock Retaining Wall Flood Control Erosion Protection

Retaining Walls Hexagonal Gabion Cage River Bank Flood Control Erosion Protection Galvanized CE ISO

The gabion box is made from low-carbon iron wire with a surface finish of galvanized, hot-dipped galvanized, galfan coated, or PVC coated, ensuring long-lasting durability and resistance to corrosion.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages

3x Lifespan: 50-100 years corrosion resistance
Load Capacity: Up to 50kN/m² vertical pressure
Eco-Friendly: 100% recyclable materials with zero chemical runoff
Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Product Specifications

Selling Units: Single item

Single package size: 305X103X108 cm

Single gross weight: 58.000 kg

Customization Services

Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

Gabion Specifications		Mesh Hole Model
Length (m)	Width (m)	Height (m)	8x10cm (Galvanized or PVC coated)	6x8cm (Galvanized or PVC coated)
2	1	1	2.7mm, Zn >245g/m²	2.0mm, Zn >215g/m²
3	1	1	Side wire 3.4mm, Zn >265g/m²	Side wire 2.7mm, Zn >245g/m²
4	1	1	Binding wire diameter of 2.7m / 2.0m
6	1	1	Binding wire diameter of 2.7m / 2.0m
