Galvanized Gabion Mesh Stone Wall For Civil Engineering And Architecture Projects

Large Image : Galvanized Gabion Mesh Stone Wall For Civil Engineering And Architecture Projects

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	gabion wall

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 15-20
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 pc per day

Contact Now Chat Now

Detailed Product Description

Product Name:	Galvanized Gabion Design For Civil Engineering And Architecture Projects	Key Words:	Gabion Wall
Material:	Galvanized Steel Wire	Size:	2m X 1m X 1m
Durability:	Long-lasting, Resistant To Corrosion And Weathering	Mesh Type:	Double Twisted Hexagonal Mesh
Application:	Erosion Control, Slope Stabilization, Riverbank Protection	Installation Method:	Laid Directly On The Ground And Filled With Stones
Surface Treatment:	Hot-dipped Galvanized
Highlight:	galvanized mesh stone wall , galvanized stone cage wall , architecture mesh stone wall

Galvanized Gabion Mesh Stone Wall

For Civil Engineering And Architecture Projects

Our galvanized gabion design offers durable solutions for civil engineering and architectural projects with a production capacity of 200,000 pieces per year and guaranteed delivery within 7 days.

Product Overview

The gabion box features heights greater than 0.5m, with mattresses commonly available in 0.17m or 0.23m heights.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²) with PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh with 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy available for marine/coastal applications
Fillers: Compatible with crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages

3x Lifespan: 50-100 years corrosion resistance

Load Capacity: Up to 50kN/m² vertical pressure

Eco-Friendly: 100% recyclable materials with zero chemical runoff

Modular Assembly: Interlocking panels for 70% faster installation

Specifications

Standard Size

2M × 1M × 1M

Surface Finish Options

Galvanized, Hot Dipped Galvanized, Galfan Coated, PVC Coated

Zinc Coating

60g, 245g, ≥270g/m²

Wire Diameter

2.0mm, 2.2mm, 2.7mm, 3.05mm

Primary Market

Philippines

Protection

Preventing of Rock Breaking

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Customization Services

Sizes: 2×1×1m (standard) up to 6×2×1m (heavy-duty)
Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

Technical Specifications

Gabion Specifications		Mesh Hole Model
Length (m)	Width (m)	Height (m)	8×10cm (Galvanized or PVC coated)	6×8cm (Galvanized or PVC coated)
2	1	1	Mesh diameter: 2.7mm, Zinc: >245g/m²	Mesh diameter: 2.0mm, Zinc: >215g/m²
3	1	1	Side wire diameter: 3.4mm, Zinc: >265g/m²	Side wire diameter: 2.7mm, Zinc: >245g/m²
4	1	1	Binding wire diameter of 2.7m / 2.0m
6	1	1	Binding wire diameter of 2.7m / 2.0m
