Hot Dip Galvanized Stone Cage Retaining Wall For Durable And Eco Friendly Construction

Large Image : Hot Dip Galvanized Stone Cage Retaining Wall For Durable And Eco Friendly Construction

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	gabion wall

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 15-20
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 pc per day

Contact Now Chat Now

Detailed Product Description

Product Name:	Hot-Dip Galvanized Stone Cage Gabion Wall For Durable And Eco-Friendly Construction	Key Words:	Gabion Wall
Specification:	60060020/25	Advantage:	Flood Control Retaining Wall
Material:	Galvanized Steel Wire	Wire Surface Treatment:	Hot-dipped Galvanized
Mesh Panel Size:	2x1x1m, 3x1x1m, 4x1x1m	Selvedge Wire Diameter:	3.4-4.0mm
Mesh Size:	60x80mm, 80x100mm, 100x120mm	Zinc Coated:	220-270g
Highlight:	galvanized stone cage retaining wall , galvanized stone cage wall , construction stone cage wall

Hot-Dip Galvanized Stone Cage Gabion Wall

Durable and Eco-Friendly Construction Solution

The Hexagonal Gabion Mesh is a versatile and eco-friendly product widely used in civil engineering and landscaping projects. These galvanized stone cages provide exceptional durability and environmental benefits for various construction applications.

Product Overview

Gabion baskets are typically packed in bundles of 40-100 sets, secured with steel straps or strands, and shipped on wooden pallets. Some sizes are available in rolls, with custom packaging options available upon request.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²) with PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh with 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy available for marine/coastal applications
Fillers: Compatible with crushed rock, recycled concrete, or vegetated soil (client-specified)
Hole Shape: Hexagonal
Wire Gauge: 2.0-4.0mm
Processing Service: Bending, Decoiling, Cutting, Punching
Tensile Strength: 38kg/m²
Standard Size: 1M × 1M × 1M
Surface Finish: Galvanized, Hot Dipped Galvanized, Galfan Coated, PVC Coated

Technical Advantages

✓ 3x Lifespan: 50-100 years corrosion resistance

✓ Load Capacity: Up to 50kN/m² vertical pressure

✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff

✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Customization Services

Sizes: 2×1×1m (standard) up to 6×2×1m (heavy-duty)
Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

Technical Specifications

Gabion Specifications		Mesh Hole Model
Length (m)	Width (m)	Height (m)	8×10cm	6×8cm
2	1	1	2.7mm (Zn >245g/m²)	2.0mm (Zn >215g/m²)
3	1	1	3.4mm (Zn >265g/m²)	2.7mm (Zn >245g/m²)
4	1	1	Binding wire diameter of 2.7m / 2.0m
6	1	1	Galvanized or PVC coated
