Hexagonal Mesh Rock Fall Protection Mesh Gabion Wire Mesh Roll Customized

Large Image : Hexagonal Mesh Rock Fall Protection Mesh Gabion Wire Mesh Roll Customized

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	CE ISO
Model Number:	2x50m 2x25m

Payment & Shipping Terms:

Minimum Order Quantity:	100roll
Price:	USD 120-140
Packaging Details:	pallets
Delivery Time:	7-10 days
Payment Terms:	L/C,T/T,Western Union,MoneyGram
Supply Ability:	1000 pc need 7 days

Contact Now Chat Now

Detailed Product Description

Features:	Flexible, Corrosion Resistant, Easy To Install	Product Name:	Standard Size Rockfall Netting Mesh 8 X 80mm(w) X 120mm (H) Zinc-Al Alloy 2.7mm 2m X 50m Gabion Wire Mesh Roll
Key Words:	Rockfall Netting	Customized:	Avaliable
Wire Diameter:	2.7mm	Zinc:	>245g/m²
Cage Size:	111m,211m,311m,411m	Net Wire:	Popular 2.7mm
Advantages:	Easy Install, Long Using Life	Season:	Everyday
Twist:	Double Twisting	Selvage Wire:	3.4mm
Highlight:	Standard rock fall protection mesh , Customized rock fall netting , 2m X 50m gabion wire mesh roll

Hexagonal Mesh Rock Fall Protection Mesh Gabion Wire Mesh Roll Customized

Standard Size Rockfall Netting Mesh

Fabricated from Galfan-coated steel wire (4.0mm diameter, 150g/m² alloy coating), this double-twisted hexagonal mesh (80x100mm apertures) forms flexible barriers for slope stabilization and rockfall mitigation in mountainous terrain.

Modular panels (3m x10m rolls) integrate high-strength steel cables (12mm diameter) along perimeters, secured to slopes via galvanized anchor rods (20mm x2.5m) spaced at 3m grids. The open structure intercepts debris while permitting drainage, with reinforced edge selvedges resisting abrasion during rock impacts. Complies with ETAG 027 guidelines for passive rockfall protection systems along transportation corridors.

Gabion Basket Specifications

Material	Galvanized low carbon steel wire
Wire Diameter	Mesh wire: 2.0mm-4.0mm Selvadge wire: 3.4mm, 3.8mm Lacing wire: 2.2mm, 2.5mm
Mesh Size	6080mm, 80100mm, 100*120mm
Gabion Size	111m, 211m, 311m, 411m, 620.3m
Surface Treatment	Hot dipped galvanized, PVC coated
Characteristics	Easy to install, rust prevention, corrosion prevention, low cost, high safety and less goods to be transported.
Usage	Water or flood control and guidance, prevention of rock breakage, coastal area protection projects, road protection.
