Heavy Galvanized Gabion Box Wire Mesh 2m Length Anti Rust Woven Hexagonal Mesh Style

Large Image : Heavy Galvanized Gabion Box Wire Mesh 2m Length Anti Rust Woven Hexagonal Mesh Style

Product Details:

Place of Origin:	Hebei ,China
Brand Name:	KN
Certification:	ISO CE
Model Number:	KN-G05

Payment & Shipping Terms:

Minimum Order Quantity:	100 boxes
Price:	USD 1.38-USD 2.66/sqm
Packaging Details:	Plastic bags
Delivery Time:	5-10 work days
Payment Terms:	L/C,D/P,T/T,Western Union
Supply Ability:	50000 sqm each week

Contact Now Chat Now

Detailed Product Description

Keyword:	Gabion Box Wire Mesh	Roll Length:	1-50m
Lacing Wire:	2.2mm	Metal Type:	Iron
Mesh Length:	2m	Weave:	Gabion Matresses,Retaining Wall
Wire Dia:	1.8-4.0mm	Technics:	Woven
Pvc Coating Color:	Green, Blue, Grey, Etc.	Daily Output:	50000 Square Meters
Frame Material:	Metal
Highlight:	galvanized gabion box wire mesh , anti rust woven gabion mesh , 2m length Gabion Box Wire Mesh

Heavy Galvanized Gabion Box Wire Mesh - 2m Length Anti-Rust Woven Hexagonal Mesh

High-quality galvanized welded stone-filled gabion wire mesh with customizable options for various construction and erosion control applications.

Product Specifications

Attribute	Value
Roll Length	1-50m
Lacing Wire	2.2mm
Metal Type	Iron
Mesh Length	2m
Weave	Gabion mattresses, Retaining wall
Wire Diameter	1.8-4.0mm
Technics	Woven
PVC Coating Color	Green, Blue, Grey, etc.
Daily Output	50000 Square meters
Frame Material	Metal

Product Description

Gabion wire baskets are constructed from heavy galvanized wire, ZnAl (Golfan) coated wire, or PVC/PE coated wires with hexagonal mesh style. These versatile baskets are ideal for slope protection, foundation pit support, mountain rock retention, and river/dam scour protection applications.

Technical Specifications

Mesh Size (mm)	Diaphragms	Length (m)	Width (m)	Height (m)	Volume (m³)	Tolerance	Color	Wire Diameter (mm)
60×80	1	2.0	1.0	0.3	0.6	Length±5% Width±5% Height±5%	Blue, Red, Green, Black	2.0-4.0
80×100	1	2.0	1.0	0.5	1.0
80×120	1	2.0	1.0	1.0	2.0
100×120	2	3.0	1.0	0.3	0.9
120×150	2	3.0	1.0	0.5	1.5
	2	3.0	1.0	1.0	3.0
	3	4.0	1.0	0.3	1.2
	3	4.0	1.0	0.5	2.0
	3	4.0	1.0	1.0	4.0
	1	2.0	0.5	0.5	0.5
	2	3.0	0.5	0.5	0.75
