Rust Proof Welded Gabion Wire Mesh Modular Garden Screen Grid Vertical Plant Frame

Large Image : Rust Proof Welded Gabion Wire Mesh Modular Garden Screen Grid Vertical Plant Frame

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	KN-gabion wire mesh

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 45-55
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 pc per day

Contact Now Chat Now

Detailed Product Description

Product Name:	Welded Gabion Wire Mesh Modular Garden Screen Rust Proof Grid Vertical Plant Frame	Key Words:	Gabion Wire Mesh
Diameter:	2.0mm-4.0mm	Opening Size:	60x80 80x100 80x120 100x120
Mesh Width:	1m	Mesh Length:	2m
Wire Diameter:	3.0mm	Characteristic:	Anti-corrosion, Easily Assembled
Highlight:	welded gabion wire mesh modular , rust proof welded gabion wire mesh , modular welded gabion mesh

Rust Proof Welded Gabion Wire Mesh Modular Garden Screen Grid Vertical Plant Frame

Galvanized Welded Gabion Mesh for Landscape Design

Crafted from premium hot-dip galvanized steel wire, our welded gabion mesh features precision-welded square or rectangular grids (typically 50×50mm to 100×100mm) for contemporary garden applications. The rigid mesh panels create clean geometric forms ideal for decorative screens, planter walls, and architectural landscape features. The zinc coating provides durable corrosion resistance while maintaining a sleek metallic finish that weathers beautifully. Standard panel sizes (1m×2m) facilitate easy construction of gabion structures for residential gardens, commercial landscapes, and urban green spaces. Custom mesh openings and wire diameters (3.0-5.0mm) available to suit specific design requirements.

Welded Gabion Basket Details

Panel: High quality galvanized panel of 50×50 or 75×75 mesh size
Spiral wires: Good quality for same wire diameter as panel
Stiffeners: 4-8 stiffeners per gabion to ensure structural strength

Welded Gabion Specifications

Type of Welded Gabion	Wire Gauge Diameter	Mesh Size	Gabion Size
Galvanized	3-5mm	50×50,75×75,50×100	2×1×1, 1×1×1,1×1×0.5, etc
PVC Coated	3.0/3.8mm	50×50,75×75,50×100	2×1×1, 1×1×1,2×1×0.5, etc
95% Zinc + 5% Al	3-5mm	50×100,75×75,100×100	1×1×0.5,2×1×1,1×1×0.3, etc

Welded Gabion Basket Connection Methods

U-clips
C-ring
Lacing wire connection
Hook connection

The spiral wires & hooks or stiffeners are most popular as they provide superior strength for usage.

Welded Gabion Basket Advantages

Economic: Just fill the stone into the gabions and seal it
Simple installation: No special technology needed
Weather proof: Corrosion resistant under natural conditions
Eco-friendly: Sludge in the stones is good for plant growth, blending with natural environment
Good permeation: Prevents damage by hydrostatic pressure
Transport efficient: Can be folded for transport and installation
Structural integrity: No collapse even under significant deformation
