Woven Gabion Wire Mesh Riverbank Slope Protection Double Weave Anti Corrosion Flood Defense

Large Image : Woven Gabion Wire Mesh Riverbank Slope Protection Double Weave Anti Corrosion Flood Defense

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	KN-gabion wire mesh

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 14-19
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 pc per day

Contact Now Chat Now

Detailed Product Description

Product Name:	Woven Gabion Wire Mesh Riverbank Slope Protection Double Weave Anti Corrosion Flood Defense	Key Words:	Gabion Wire Mesh
Mesh:	60x80 80x100	Tensile Strength:	350-500N/mm2
Color:	Slive	Mesh Panel Size:	2x1x1m
Mesh Size:	60*80mm	Length:	Customzied
Process:	Woven Mesh	Hole Sizes:	80*120mm, Etc.
Highlight:	woven gabion wire mesh , woven gabion basket

Woven Gabion Wire Mesh Riverbank Slope Protection Double Weave Anti Corrosion Flood Defense

Woven Gabion Wire Mesh for Hydraulic Engineering

Constructed from double-twisted hexagonal steel wire (2.2-4.0mm diameter) with galvanized or PVC coating, our woven gabion mesh forms durable, flexible structures for water control projects. The standard 60×80mm to 100×120mm mesh openings create permeable barriers when assembled into mattresses, boxes, or sacks. Primarily used for riverbank protection, coastal revetments, channel lining, and dam face stabilization. The mesh conforms to subgrade contours while resisting hydraulic forces. Manufactured in rolls or pre-assembled panels meeting EN 10223-3 specifications. Custom wire diameters and mesh sizes available for various hydraulic applications requiring erosion control and slope stabilization.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages

3x Lifespan: 50-100 years corrosion resistance
Load Capacity: Up to 50kN/m² vertical pressure
Eco-Friendly: 100% recyclable materials with zero chemical runoff
Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Customization Services

Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

Gabion Specifications

Mesh Hole Model	8x10cm
Mesh Hole Model	Galvanized or PVC coated	Galvanized or PVC coated
Length (m) / Width (m) / Height (m)	Mesh diameter: 2.7mm Zinc: >245g/m²	Mesh diameter: 2.0mm Zinc: >215g/m²
2 \| 1 \| 1	Side wire diameter: 3.4mm Zinc: >265g/m²	Side wire diameter: 2.7mm Zinc: >245g/m²
3 \| 1 \| 1	Binding wire diameter: 2.7mm	Binding wire diameter: 2.0mm
