60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas

60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas
60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas 60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas

Large Image :  60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas

Product Details:
Place of Origin: CHINA
Brand Name: KN
Certification: ISO CE
Model Number: 6X2X0.3
Payment & Shipping Terms:
Minimum Order Quantity: 100pc
Price: USD 16-20
Packaging Details: pallets
Delivery Time: 7-8 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000m2 per day
Contact Now Chat Now
Detailed Product Description
Features: Flexible, Durable, Easy To Install Product Name: Design Services Manufacturing Facilities 60x80mm Gabion Reno Mattress For Civil Engineering And Construction
Surface Treatment: Hot-dipped Galvanized, Galfan Coated Mesh Size: 60x80mm, 80x100mm, 100x120mm
Wire Diameter: 2.0-4.0mm Material: Galvanized Steel Wire
Tie Wire: 2.2mm Application: Erosion Control, Slope Stabilization, Riverbank Protection
Color: Silver Or Green Zinc Coating: 240-290g/m2
Size: 2x1x1m, 3x1x1m, 4x1x1m, Or Customized Packing: Packed In Bundles Or On Pallets
Highlight:

60x80mm Gabion Reno Mattress

,

Gabion Reno Mattress For Riverbanks

,

Gabion Reno Mattress For Channels

60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas
Woven Gabion Mattress for Hydraulic Engineering
Constructed from double-twisted hexagonal steel mesh (2.2-4.0mm wire) with galvanized or PVC coating, our gabion mattresses provide flexible erosion protection for riverbanks, channels, and coastal areas. The low-profile design (150-300mm thickness) with 60×80mm to 100×120mm mesh openings allows stone filling while maintaining permeability. Used for slope stabilization, scour protection, and bed reinforcement in watercourses. Complies with EN 10223-3 standards. Custom sizes available for hydraulic projects requiring durable, permeable revetment solutions.
Specification
Product Name Gabion
Hole Type Hexagonal
Production process Three twist / Five twist
Material GI wire, PVC coated wire, galfan wire
Wire Diameter 2.0mm-4.0mm
Hole Size 60×80mm, 80×100mm, 100×120mm, 120×150mm
Gabion Size 2m×1m×0.5m, 2m×1m×1m, 3m×1m×0.5m, 3m×1m×1m, 4m×1m×0.5m, 4m×1m×1m, Other sizes can be customized.
Gabion Features
  • Economical: Just put the stone into the cage and seal it.
  • Simple construction without special technology required.
  • Strong resistance to natural damage, corrosion, and adverse climate impact.
  • Can withstand large-scale deformation without collapse.
  • Silt between stone gaps promotes plant growth and environmental integration.
  • Excellent permeability prevents hydrostatic force damage.
  • Cost-effective transportation: folds for transport and assembles on-site.
  • Flexible structure with no structural joints and overall ductility.
  • Corrosion-resistant galvanized materials suitable for seawater environments.
  • Environmentally friendly materials compliant with RoHS standards.
Key Features and Benefits
  • Durability and Longevity: Corrosion-resistant materials ensure exceptional performance in harsh conditions.
  • Flexibility: Customizable to project requirements for size, shape, and filling material.
  • Environmental Friendliness: Promotes ecological balance through drainage and wildlife habitat creation.
  • Cost-Effectiveness: More economical than traditional retaining walls with minimal maintenance.
  • Permeability: Stone fill allows water flow while retaining soil, eliminating hydrostatic pressure issues.
Applications
  • Erosion Control: Stabilizes soil in riverbanks, coastal areas, and slopes.
  • Slope Stabilization: Reinforces steep slopes to prevent landslides.
  • Channel Lining and Bank Protection: Durable linings for channels and culverts.
  • Landscaping: Enhances outdoor spaces while blending with natural surroundings.
Free Design Services
We understand that every project is unique. Our experienced design team provides free design drawings and support for your engineering projects, including CAD or 3D drawings.
60x80mm Steel Wire Gabion Reno Mattress For Riverbanks / Channels / Coastal Areas 0
