Double Twisted Class A Gabion Mesh Cage Hexagonal Steel Mesh Gabion Cages

Large Image : Double Twisted Class A Gabion Mesh Cage Hexagonal Steel Mesh Gabion Cages

Product Details:

Place of Origin:	CHINA
Brand Name:	KN
Certification:	ISO CE
Model Number:	1X1X1 2x1x1 3x1x1

Payment & Shipping Terms:

Minimum Order Quantity:	100pc
Price:	USD 17-20
Packaging Details:	pallets
Delivery Time:	7-8 days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5000mw per day

Contact Now Chat Now

Detailed Product Description

Product_Name:	Double Twisted Class A Hexagonal Steel Mesh Gabion Cages For Modern Retaining Walls	Surface Treatment:	Hot-dipped Galvanized/PVC Coated
Zinc Coating:	≥ 270g/m²	Size:	2m X 1m X 1m
Application:	Erosion Control, Retaining Walls, Landscaping	Elongation:	≥ 10%
Wire Diameter:	3.05mm	Material:	Galvanized Steel Wire
Durability:	Long-lasting	Tensile Strength:	350-500N/mm²
Mesh Size:	80mm X 100mm 100x120mm	Installation:	Easy And Quick
Connectors:	Binding Lacing Wire	Assembly Method:	Binding Lacing Wire
Highlight:	Class A Gabion Mesh Cage , Double twisted gabion mesh , Gabion cages for retaining walls

Double Twisted Class A Gabion Mesh Cage Hexagonal Steel Mesh Gabion Cages

Double Twisted Class A Hexagonal Steel Mesh Gabion Cages for Retaining Walls

Product Specifications

Attribute	Value
Surface Treatment	hot-dipped galvanized/PVC coated
Zinc Coating	≥ 270g/m²
Size	2m x 1m x 1m
Application	erosion control, retaining walls, landscaping
Elongation	≥ 10%
Wire Diameter	3.05mm
Material	galvanized steel wire
Durability	long-lasting
Tensile Strength	350-500N/mm²
Mesh Size	80mm x 100mm 100x120mm
Installation	easy and quick
Connectors	binding lacing wire

Key Advantages

Geometric Strength: The six-sided cell distributes earth pressure evenly, reducing bulging by up to 30% compared to traditional square gabions.
Rapid Assembly: Fold-flat panels with integrated helical fasteners install 40% faster; no onsite welding or specialized tools required.
Design Flexibility: Stack, curve, or terrace the units to create retaining walls, seating, planters, or sound barriers up to 6m high.
Eco-Friendly Fill: Compatible with recycled concrete, native stone, or glass aggregate for LEED credits and localized visual harmony.
Low Maintenance: PVC or zinc-aluminum coating options withstand freeze-thaw cycles and salt spray without cracking or spalling.

Product Features

Economical - just fill with stone and seal
Easy construction without special techniques
Strong resistance to natural damage, erosion, and adverse weather
Can withstand large-scale deformation without collapsing
Silt between stones promotes plant growth and environmental integration
Excellent permeability prevents hydrostatic pressure damage
Cost-effective shipping - folds for transport and assembles on-site
Fast installation enables parallel construction for tight deadlines

Technical Parameters

Mesh Size	Wire Diameter	Diaphragm	Length	Width	Height	Area	Color	Surface Treatment
60×80mm 80×100mm 80×110mm 100×120mm 120×150mm	2.0-4.0mm (2.2mm, 2.7mm, 3.0mm, 3.05mm common)	1	2m	1m	0.5m	7.5㎡	Silver Dark Green Gray Black	Hot dip galvanized PVC coated PE coated Galfan
		1	2m	1m	1m	11㎡
		2	3m	1m	0.5m	10.5㎡

Applications

A versatile material structure for transportation, water conservancy, municipal engineering, landscaping, soil and water conservation projects. Product varieties include:
