Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall

Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall
Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall

Large Image :  Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall

Product Details:
Place of Origin: CN
Brand Name: KN
Certification: CE ISO SGS COC PVOC
Model Number: KN-gabion cages
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pc
Price: USD 35-49
Packaging Details: pallet
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 pc per day
Contact Now Chat Now
Detailed Product Description
Features: Flexible, Easy To Install, Corrosion Resistant Product Name: Hexagonal Gabion Wall For Water Protection: Flood Defense, Corrosion-Resistant, Eco-Friendly
Key Words: Gabion Cages Type: Weave
Application: Retaining Walls, Erosion Control, River Bank Protection Wire Type: Hexagonal Wire Mesh
Sample: Available Tensible Strength: 350-550N/mm
Tie Wire: 2.70mm Mesh Size: 60x80mm, 80x100mm, 100x120mm
Highlight:

Hexagonal Gabion Wall

,

Galvanized Steel Flood Barrier

,

Steel Gabion Mesh Cage 2x1x1m

Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall
Product Overview
Hexagonal Gabion Wall - Galvanized Steel Flood Defense Barrier (2x1x1m) designed for water protection, flood defense, and erosion control with superior corrosion resistance and eco-friendly properties.
Key Specifications
Attribute Value
Product Name Hexagonal Gabion Wall For Water Protection
Type Weave
Application Retaining walls, erosion control, river bank protection
Wire Type Hexagonal wire mesh
Tensile Strength 350-550N/mm
Tie Wire 2.70mm
Mesh Size Options 60x80mm, 80x100mm, 100x120mm
Product Description
The hexagonal gabion mesh is manufactured by weaving high-quality metal wires including galvanized wire, zinc-aluminum alloy wire, and PVC/PE-coated wire. These materials provide exceptional corrosion resistance and durability in various weather conditions. The mesh sizes range from 60-120 x 80-150 millimeters to accommodate different project requirements. Thicker border lines enhance structural stability.
Key Features
  • Material: Hot-dip galvanized steel (Zn ≥ 250g/m²) with PVC-coated options (0.5mm thickness)
  • Design: Hexagonal double-twist mesh with 90x110mm standard apertures (customizable)
  • Coatings: Epoxy/Zinc-Aluminum alloy available for marine/coastal applications
  • Fillers: Compatible with crushed rock, recycled concrete, or vegetated soil (client-specified)
Product Advantages
  • Superior Strength: Heavy-duty double-twisted steel mesh withstands hydraulic pressure
  • Excellent Flexibility: Adapts to ground settlement without structural damage
  • High Permeability: 95% water flow reduces hydrostatic pressure
  • Long Service Life: Corrosion-resistant coating ensures 30+ year durability
Applications
  • Civil Engineering: Riverbank stabilization, highway embankments
  • Architecture: Retaining walls, sound barriers, decorative façades
  • Disaster Prevention: Flood control barriers, landslide mitigation systems
  • Mining: Tailings dam reinforcement, slope retention
Customization Services
  • Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
  • Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
Technical Specifications
Gabion Specifications Mesh Hole Model
8x10cm 6x8cm
Length (m) Width (m) Height (m) Galvanized or PVC coated Galvanized or PVC coated
2 1 1 2.7mm >245g/m² 2.0mm >215g/m²
3 1 1 Side wire diameter 3.4mm >265g/m² Side wire diameter 2.7mm >245g/m²
4 1 1 Binding wire diameter of 2.7m Binding wire diameter of 2.0m
6 1 1 Custom specifications available
Flood Defense Barrier Galvanized Steel Gabion Mesh Cage 2x1x1m Hexagonal Gabion Wall 0

Tag:

gabion cage box,

gabion rock cage,

gabion stone cages
