275g Zinc Coated Galvanized Gabion Cages With Iron Wire Mesh

Large Image : 275g Zinc Coated Galvanized Gabion Cages With Iron Wire Mesh

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	CE, ISO, COC,BESC
Model Number:	KNG01

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	USD 17-20
Packaging Details:	pallet or bundle
Delivery Time:	7
Payment Terms:	L/C,Western Union,MoneyGram,T/T
Supply Ability:	1 40-foot high containers in 7 days

Contact Now Chat Now

Detailed Product Description

Product Name:	275g Zinc Coated Galvanized Iron Wire Mesh Gabion Cages For Sale	Key Word:	Gabion Cages
Material:	Galvanized Iron Wire,Low-Carbon Iron Wire,pvc Wire, Galfan Wire	Hole Shape:	Hexagonal, Double Twist
Wire Gauge:	2.4mm, 2.5mm, 2.7mm, 2.8mm, 3.05mm	Application:	Gabions,Cages,slope Protection,Fence Mesh,Construction Wire Mesh
Type:	Hexagonal Wire Mesh, Double Twist	Aperture:	80100mm,100120mm,60*80mm,etc,
Surface Treatment:	Hot Dipped Galvanized, PVCcoated, Galvanized+PVC Coated	Product Name:	Gabion Box, Gabion Box Wire Mesh,Gabion Basket,Hot Sale 2x1x1m PVC Coated Heavy Duty Gabion
Color:	Green,black,	Packing:	Pallet,Bundle
Highlight:	galvanized gabion cages , galvanized gabion basket , zinc coated gabion cages

275g Zinc Coated Galvanized Gabion Cages With Iron Wire Mesh

Constructed of hot-dip galvanized steel wire (4.5mm core, 300g/m² coating), this double-twist gabion (1.5m x1m x0.5m) features 80x100mm apertures and wave-shaped diaphragms at 1m intervals for river confluence revetments. Reinforced edges (6mm wire) and stainless steel C-rings (304 grade) connect units, accommodating 80-180mm basalt infill. Integrated 50mm diameter drainage pipes (PVC) at base sections mitigate pore pressure in clay-dominated banks. Complies with JIS G 3353 for hydraulic structures, with optional sacrificial zinc anodes for brackish water interface zones.

Standard Gabion Basket Sizes

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	1	0	1
2	1	1	1	2
3	1	1	2	3
4	1	1	3	4
5	1	1	4	5
6	1	1	5	6

Other sizes available for customization

Standard Gabion Mattress Sizes

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	0.3/0.5	0	0.3/0.5
2	1	0.3/0.5	1	0.6/1
3	1	0.3/0.5	2	0.9/1.5
4	1	0.3/0.5	3	1.2/2
5	2	0.3/0.5	4	3/5
6	2	0.3/0.5	5	3.6/6

Other sizes available for customization

Product Applications

Erosion Control: Stabilizes slopes and riverbanks, preventing soil erosion while allowing proper water drainage.
Retaining Walls: Constructs secure, aesthetically pleasing walls for residential and commercial landscapes.
Flood Protection: Forms durable barriers to divert water flow and protect infrastructure from flood damage.
Coastal Defense: Stabilizes shorelines against wave action and protects coastal properties from erosion.
Road Embankments: Reinforces transportation routes by retaining soil and preventing landslides.
Bridge Construction: Strengthens abutments and foundations for enhanced structural integrity.

Technical Specifications

Parameter	Description	Typical Value / Range
Material	Base material used for constructing the mesh	HDP/Galvanized Wire, PVC Wire
Coating	Surface treatment for enhanced corrosion resistance	Galvanized, HDP Galvanized, PVC Coated
Wire Diameter	The thickness of the wires used in the mesh	Mesh Wire: 2.0~3.05mm Selvage Wire: 2.4~4.0mm Tie Wire: 2.0~2.4mm
Mesh Opening Size	The size of the openings between wires	60×80mm, 80×100mm, 100×120mm, 120×150mm
Overall Dimensions	Standard Gabion Roll and Basket Sizes	Roll Width: 1~4m Basket: 1×1×1m to 6×1×1m
Lifespan	Expected service life	6~20 years (environment dependent)
