Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material

Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material
Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material

Large Image :  Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material

Product Details:
Place of Origin: CN
Brand Name: KN
Certification: CE ISO SGS COC PVOC
Model Number: KN-gabion cage
Payment & Shipping Terms:
Minimum Order Quantity: 100 pc
Price: USD 17-20
Packaging Details: pallet
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 pc per day
Contact Now Chat Now
Detailed Product Description
Product Name: Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material Key Words: Gabion Cage
Material: Galvanized Steel Wire Zinc Coating: 220-240g/m2
Durability: Long-lasting Wire Diameter: 2.7mm
Tensile Strength: 350-550N/mm2 Corrosion Resistance: Highly Resistant To Rust And Corrosion
Surface Treatment: Hot-dipped Galvanized Mesh Size: 76.2mm X 76.2mm
Flexibility: Easy To Install And Shape Size: 2m X 1m X 1m
Highlight:

woven gabion cages

,

woven gabion basket

,

2.7mm gabion cages

Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material
Woven Gabion Cages for Hydraulic Engineering

Engineered for demanding water control projects, our heavy-duty woven gabion cages feature double-twisted hexagonal steel mesh (3.0-4.0mm wire) with superior corrosion resistance (hot-dip galvanized or PVC-coated). The 80×100mm mesh design provides optimal stone retention while maintaining 95%+ water permeability, effectively reducing flow velocity by 40-60%. Ideal for riverbank stabilization, flood defense systems, and coastal protection works. Flexible yet durable construction accommodates ground movement while withstanding 5m/s water currents. Certified to international standards (EN 10223-3) with 30+ year lifespan. Custom configurations available for large-scale hydraulic applications requiring reliable, eco-friendly solutions.

Key Features
  • Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
  • Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
  • Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
  • Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)
Product Advantages
1. Superior Strength - Heavy-duty double-twisted steel mesh withstands hydraulic pressure
2. Excellent Flexibility - Adapts to ground settlement without structural damage
3. High Permeability - 95% water flow reduces hydrostatic pressure
4. Long Service Life - Corrosion-resistant coating ensures 30+ year durability
Applications
  • Civil Engineering: Riverbank stabilization, highway embankments
  • Architecture: Retaining walls, sound barriers, decorative façades
  • Disaster Prevention: Flood control barriers, landslide mitigation systems
  • Mining: Tailings dam reinforcement, slope retention
Customization Services
  • Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
  • Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
Gabion Specifications
Mesh hole model 8x10cm 6x8cm
Length(m) Width(m) Height(m) Galvanized or PVC coated Galvanized or PVC coated
Mesh diameter Zinc Mesh diameter Zinc
2 1 1 2.7mm >245g/m² 2.0mm >215g/m²
3 1 1 Side wire diameter Zinc Side wire diameter Zinc
4 1 1 3.4mm >265g/m² 2.7mm >245g/m²
6 1 1 Binding wire diameter of 2.7m Binding wire diameter of 2.0m
Woven Gabion Cage Wetland Restoration Eco Friendly Erosion Control Recycled Material 0
