Bulk Welded Gabion Wall Retaining Wall Free Design Support Rock Filled Retaining Wall

Large Image : Bulk Welded Gabion Wall Retaining Wall Free Design Support Rock Filled Retaining Wall

Product Details:

Place of Origin:	Hebei,China
Brand Name:	KN
Certification:	ISO CE
Model Number:	KN-W07

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	USD 39-45
Packaging Details:	Wooden pallets
Delivery Time:	7-15 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	10000 pcs each month

Contact Now Chat Now

Detailed Product Description

Product Name:	Welded Gabion	Key Word:	Real Factory Of Welded Gabion Cage
Advantage:	High Quality With Good Price	Usage:	Retaining Wall
Certificated:	CE,ISO	Feature:	Corrosion Resistance ,etc.
Finish:	Galvanized Or PVC Coated	Material:	Galvanized Steel Wire
Payment:	T/T Or L/C	Package:	Compaction And Bundle Or In Pallet
Highlight:	welded gabion wall retaining wall , bulk gabion wall retaining wall , bulk rock filled retaining wall

Bulk Welded Gabion Wall Retaining Wall Free Design Support Rock Filled Retaining Wall

Bulk Welded Gabion Supplies: Affordable Garden Stone Cages with Free Design Support

Our welded stone cages are constructed from high-tensile steel wire (2.0mm to 4.0mm diameter) with dual protection:

Hot-dip galvanizing: 220-300g/m² zinc coating for saltwater/acid rain resistance (ASTM A641 compliant).
PVC-coated option: 0.5mm-thick polymer layer in green/grey/black, ideal for UV-heavy climates.

The hexagonal or square welded grid (50x50mm to 150x150mm) prevents stone spillage while allowing natural drainage. Reinforced edges with 10% thicker wire at joints ensure load-bearing capacity up to 35kN/m².

We support customize any sizes, here are some common sizes:

Material	Galvanized Steel Wire, Galfan Steel Wire/Zinc-5%Aluminum Wire
Wire Diameter	3 mm, 4 mm, 5 mm, 6 mm, etc
Aperture	50×50 mm, 50×100 mm, 75×75 mm, etc
Gabion Box Size	100×30×30 cm, 100×50×30 cm, 100×100×50 cm, 100×100×100 cm etc. Other sizes can be customized
Finish	Hot Dipped Galvanized; Heavy Zinc Coating; Galfan Coating; PVC Coated.
Advantage	Easy to install, Anti-rust and anti-corrosive, Low cost High security, Beautiful appearance

Application of welded box gabion

Main application of welded gabion mesh:

Rockfall prevention and soil erosion protection, strengthening structure of soil
Bridge protection; embankment protection
Prevention of current scour and erosion control
Protection engineering of seaside area and welded gabion retaining wall structures
Hydraulic structures, dams and culverts
