200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping

200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping
200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping

Large Image :  200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping

Product Details:
Place of Origin: CN
Brand Name: KN
Certification: CE ISO SGS COC PVOC
Model Number: KN-gabion basket
Payment & Shipping Terms:
Minimum Order Quantity: 100 pc
Price: USD 35-45
Packaging Details: pallet
Delivery Time: 15 work days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 500 pc per day
Contact Now Chat Now
Detailed Product Description
Highlight:

200x100x50 welded gabion baskets

,

200x100x50 welded mesh gabion baskets

,

garden welded gabion baskets

Galvanized Welded Mesh Gabion Box
These welded gabion boxes provide a robust, high-quality solution for flood control and erosion protection. Manufactured by KN Factory, they feature a galvanized coating for superior corrosion resistance, making them ideal for harsh weather conditions and outdoor environments. The 50x200mm mesh size and 5.0mm wire thickness offer exceptional strength and stability to support heavy loads and withstand external pressures.
Material Specifications
Material Galvanized Steel Wire, Galfan Steel Wire/Zinc-5%Aluminum Wire
Wire Diameter 3 mm-6 mm
Aperture 50*50 mm, 50*100 mm etc
Gabion Box Size 100*30*30 cm, 100*50*30 cm, 100*100*50 cm, 100*100*100 cm etc.
Finish Hot Dipped Galvanized; Heavy Zinc Coating; Galfan Coating; PVC Coated
Standard Dimensions
Normal Box Size (cm) Diaphragms Capacity (m3) Mesh Size (mm)
100x30x30 None 0.09 50×50 or 100×50
100x50x30 None 0.15
100x100x50 None 0.5
100x100x100 None 1
150x100x50 1 0.75
150x100x100 1 1.5
200x100x50 1 1
200x100x100 1 2
Other sizes can be customized.
Technical Specifications
  • Fabric Type: Galvanized welded mesh
  • Tensile Strength (wire): Welded: 540 to 770 N/mm²
  • Weld Strength: 75% of the minimum ultimate tensile strength of the wire
  • Available wire thicknesses: 3.0mm, 4.0mm, 5.0mm
  • Mesh Aperture: 75x75mm, 50x50mm, 50x100mm, 50x200mm
  • Standard basket lengths: 1000mm, 1500mm or 2000mm, 500mm etc
  • Standard basket widths: 450mm, 500mm, 300mm, 200mm, 1000mm, 1500mm
  • Standard basket heights: 500mm, 1000mm
  • Bespoke Sizes Available
Applications
  • Retaining Walls: Stabilizing slopes, preventing soil erosion, and supporting embankments in residential and commercial projects.
    • 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 0
  • Erosion Control: Effective for controlling soil erosion along riverbanks, coastlines, and steep slopes with stable, permeable structures.
    • 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 1
  • Flood Protection: Creating flood barriers or levees to protect vulnerable areas from floodwaters.
    • 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 2
  • Landscaping Features: Decorative garden walls, seating areas, and planters combining functionality with aesthetic appeal.
    • 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 3
Product Gallery
200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 4 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 5 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 6 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 7 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 8 200x100x50 Welded Gabion Baskets Metal Box Retaining Wall Filling Stone for Flood Control and Garden Landscaping 9
