Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy

Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy
Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy

Large Image :  Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy

Product Details:
Place of Origin: China
Brand Name: KN
Certification: CE ISO
Model Number: 2X1X1 3X1X1 4X1X1 6X2X0.3
Payment & Shipping Terms:
Minimum Order Quantity: 100pc
Price: USD 12-17
Packaging Details: pallets
Delivery Time: 7-10 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 pc need 7 days
Contact Now Chat Now
Detailed Product Description
Features: Flexible, Corrosion Resistant, Easy To Install Stock: Have Large Stock
Tensile Strength: 350-550N/mm2 Customized: Avaliable
Wire Diameter: 2.7mm Zinc: >245g/m²
Cage Size: 1*1*1m,2*1*1m,3*1*1m,4*1*1m Net Wire: Popular 2.7mm
Advantages: Easy Install, Long Using Life Season: Everyday
Twist: Double Twisting Selvage Wire: 3.4mm
Lacing Wire: Common Use 2.2mm Product Name: Flexible And Durable Pvc Coated Galvanized Steel Wire Gabion Basket For Water Conservancy And Eco-Projects With Hexagonal Wire Mesh Netting
Highlight:

Gabion retaining wall baskets

,

Pvc Coated retaining wall baskets

,

Durable gabion basket suppliers

Flexible And Durable PVC Coated Gabion Retaining Wall Baskets For Water Conservancy
Product Description
Flexible PVC Coated Gabion Basket for Water Conservancy and Eco-Projects featuring hexagonal wire mesh designed for scour and corrosion resistance.
Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy 0
These baskets feature variable-density hexagonal mesh (60-150mm openings) with dual-coated steel wire (Zn+Polymer), addressing complex hydraulic challenges in delta regions and variable-flow environments. Engineered with quick-connect lacing systems for rapid deployment in emergency flood response, they integrate with bioengineering techniques for bank stabilization in ecologically sensitive waterways.
Designed to meet USACE EM 1110-2-1601 specifications, the baskets accommodate hybrid fill materials (stone with root reinforcement) for combined structural and vegetative stabilization. Specialized versions available with sacrificial anode systems for brackish water applications.
Services
Pre-sales Services:
  • Free samples available (freight to be paid by the customer)
  • Ample inventory for quick delivery
  • A variety of styles to choose from
After-sales Services:
  • We welcome customers' suggestions on prices and products
  • If you have any questions, feel free to contact us via email or phone at any time
Product Overview
Gabion baskets are containers made of hexagonal double-twisted steel wire mesh. They are typically filled with stones on-site to form a flexible, permeable single structure and are widely used in water conservancy projects and environmental protection fields. They feature modular and stackable designs, allowing them to adapt to different shapes and terrains. Moreover, gabion baskets are known for their scour resistance, deformation resistance, and corrosion resistance.
Product Specifications
  • Mesh Size: 60×80 mm, 80×100 mm, 100×120 mm, or custom sizes available
  • Dimensions:
    • Length: 1-6 meters
    • Width: 0.23-2 meters
    • Height: 0.3-1 meter
  • Wire Diameter: 2.0-4.0 mm
  • Surface Treatment: Galvanizing, hot-dip galvanizing, PVC coating, Galfan coating
Mesh Sizes (mm) Gabion basket dimensions and volumes Wire diameter
60*80
80*100
100*120		 L(M): 4
W(M): 2
D(M): 0.3
Capacity(m³): 2.4
Number of diaphragm: 3		 Mesh Wire:
2.0mm,2.2mm
2.5mm, 2.7mm,3.05mm.
2.0/3.0mm,2.2/3.2mm
2.5/3.5mm,2.7/3.7mm.

selvedge wire:
2.5mm,2.7mm
3.2mm,3.4mm,3.8mm
2.5/3.5mm,2.7/3.7mm
3.2/4.2mm,3.4/4.4mm

lacing wire:
2.0mm,2.2mm
2.0/3.0mm,2.2/3.2mm
L(M): 6
W(M): 2
D(M): 0.3
Capacity(m³): 3.6
Number of diaphragm: 5
L(M): 4
W(M): 2
D(M): 0.23
Capacity(m³): 1.84
Number of diaphragm: 3
L(M): 6
W(M): 2
D(M): 0.23
Capacity(m³): 2.76
Number of diaphragm: 5
L(M): 2
W(M): 1
D(M): 0.5
Capacity(m³): 1
Number of diaphragm: 1
L(M): 3
W(M): 1
D(M): 0.5
Capacity(m³): 1.5
Number of diaphragm: 2
L(M): 4
W(M): 1
D(M): 0.5
Capacity(m³): 2
Number of diaphragm: 3
L(M): 2
W(M): 1
D(M): 1
Capacity(m³): 2
Number of diaphragm: 1
L(M): 3
W(M): 1
D(M): 1
Capacity(m³): 3
Number of diaphragm: 2
L(M): 4
W(M): 1
D(M): 1
Capacity(m³): 4
Number of diaphragm: 3
Other specifications can also be customized processing.
Product Advantages
  • Cost-effective: Simply fill with stones and seal for use
  • Easy Installation: No special skills required
  • Weather-resistant: Good corrosion resistance in natural environments
  • Eco-friendly: The gaps between stones allow silt to accumulate, which is conducive to plant growth and can blend with the natural environment
  • Low Transportation Costs: Foldable for transportation and then unfolded on-site
Application Fields
  • Water Conservancy Projects: Used for embankments, riverbank protection, and waterway lining to effectively prevent scouring by water flow
  • Environmental Protection: Plays an important role in ecological restoration and soil conservation
  • Road Protection: Protects road foundations, enhancing the stability and durability of roads
  • Coastal Protection: Used in seawalls and port projects to resist wave erosion
Cooperation and Services
As a professional manufacturer, we are committed to providing high-quality gabion basket solutions for global water conservancy and environmental protection projects. We maintain close cooperation with government departments in various countries and have provided reliable product support for numerous water conservancy and environmental protection projects.
Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy 1 Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy 2 Flexible And Durable Pvc Coated Gabion Retaining Wall Baskets For Water Conservancy 3
We sincerely welcome partners from all over the world to join our sales network and work together to promote the application of gabion baskets in global water conservancy and environmental protection projects.
