Flexible Pvc Coated Gabion Basket Hexagonal Wire Mesh for Scour and Corrosion Resistance

Flexible Pvc Coated Gabion Basket Hexagonal Wire Mesh for Scour and Corrosion Resistance
Flexible Pvc Coated Gabion Basket Hexagonal Wire Mesh for Scour and Corrosion Resistance Flexible Pvc Coated Gabion Basket Hexagonal Wire Mesh for Scour and Corrosion Resistance

Large Image :  Flexible Pvc Coated Gabion Basket Hexagonal Wire Mesh for Scour and Corrosion Resistance

Product Details:
Place of Origin: China
Brand Name: KN
Certification: CE ISO
Model Number: 2X1X1 3X1X1 4X1X1 6X2X0.3
Payment & Shipping Terms:
Minimum Order Quantity: 100pc
Price: USD 12-17
Packaging Details: pallets
Delivery Time: 7-10 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 pc need 7 days
Contact Now Chat Now
Detailed Product Description
Features: Flexible, Corrosion Resistant, Easy To Install Product Name: Flexible Pvc Coated Gabion Basket For Water Conservancy And Eco-Projects Hexagonal Wire Mesh For Scour And Corrosion Resistance
Stock: Have Large Stock Tensile Strength: 350-550N/mm2
Customized: Avaliable Wire Diameter: 2.7mm
Zinc: >245g/m² Cage Size: 1*1*1m,2*1*1m,3*1*1m,4*1*1m
Net Wire: Popular 2.7mm Advantages: Easy Install, Long Using Life
Season: Everyday Twist: Double Twisting
Selvage Wire: 3.4mm Lacing Wire: Common Use 2.2mm
Highlight:

gabion basket hexagonal

,

pvc coated gabion basket

,

hexagonal gabion cages

Flexible PVC Coated Gabion Basket Hexagonal Wire Mesh
Scour and Corrosion Resistant Solution for Water Conservancy & Eco-Projects

Our double-twisted hexagonal steel mesh gabion baskets (3.5-5.0mm wire) feature enhanced hot-dip galvanization (300g/m² coating) for extreme hydraulic conditions. The reinforced corner braces and cross-partitions make them ideal for port protection, riverbed scouring prevention, and irrigation canal reinforcement.

ISO 1461-compliant and CE-certified for EU water infrastructure projects, these baskets are designed to integrate with concrete foundations in high-velocity zones. Typically filled with graded basalt/granite (150-250mm), they stabilize critical junctions in estuarine and high-sediment environments.

Product Specifications
  • Mesh Sizes: 60×80 mm, 80×100 mm, 100×120 mm (custom sizes available)
  • Dimensions: Length: 1-6m | Width: 0.23-2m | Height: 0.3-1m
  • Wire Diameter: 2.0-4.0 mm
  • Surface Treatment: Galvanizing, hot-dip galvanizing, PVC coating, Galfan coating
Mesh Sizes (mm) Length (M) Width (M) Depth (M) Capacity (m³) Diaphragms
60×80
80×100
100×120		 4 2 0.3 2.4 3
6 2 0.3 3.6 5
4 2 0.23 1.84 3
6 2 0.23 2.76 5
2 1 0.5 1 1
3 1 0.5 1.5 2
4 1 0.5 2 3
2 1 1 2 1
3 1 1 3 2
4 1 1 4 3
Other specifications available for custom processing
Key Advantages
  • Cost-effective: Simply fill with stones and seal for immediate use
  • Easy Installation: No special skills required
  • Weather-resistant: Excellent corrosion resistance in natural environments
  • Eco-friendly: Promotes plant growth through natural silt accumulation
  • Transport Efficient: Foldable design reduces shipping costs
Application Fields
  • Water Conservancy: Embankments, riverbank protection, waterway lining
  • Environmental Protection: Ecological restoration, soil conservation
  • Road Protection: Foundation stabilization for enhanced durability
  • Coastal Protection: Seawalls and port projects against wave erosion
Our Services
Pre-sales Support
  • Free samples available (customer pays freight)
  • Ample inventory for quick delivery
  • Multiple style options
After-sales Support
  • We welcome customer feedback on pricing and products
  • Available for technical consultation via email or phone
