Heavy Duty Pre Made Gabion Baskets Hydraulic Engineering Slope Stabilization Zinc Coated

Large Image : Heavy Duty Pre Made Gabion Baskets Hydraulic Engineering Slope Stabilization Zinc Coated

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	KN-gabion basket

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 12-17
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	500 pc per day

Contact Now Chat Now

Detailed Product Description

Product Name:	Heavy Duty Gabion Basket Hydraulic Engineering Slope Stabilization Zinc Coated	Key Words:	Gabion Basket
Edge Wire:	3.4mm	Material:	Galvanized Steel Wire
Wire Diameter:	2.0-4.0mm	Zinc Coating:	≥240g/m²
Aperture:	60x80mm	Mesh Shape:	Hexagonal
Tensile Strength:	350-500N/mm²	Surface Treatment:	Hot-dip Galvanized, Electro Galvanized
Highlight:	Heavy Duty pre made gabion baskets , Zinc Coated pre made gabion baskets , Zinc Coated rock basket fence

Heavy Duty Pre Made Gabion Baskets Hydraulic Engineering Slope Stabilization Zinc Coated

Woven Gabion Baskets for Hydraulic Engineering

Specially designed for water control projects, our heavy-duty woven gabion baskets provide reliable erosion protection and bank stabilization. The double-twisted hexagonal steel mesh construction offers superior strength and flexibility to withstand strong water currents.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages

3x Lifespan: 50-100 years corrosion resistance

Load Capacity: Up to 50kN/m² vertical pressure

Eco-Friendly: 100% recyclable materials with zero chemical runoff

Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Customization Services

Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

Gabion Specifications

Mesh hole model	8x10cm
Mesh hole model	Galvanized or PVC coated	Galvanized or PVC coated
Length(m) x Width(m) x Height(m)	Mesh diameter: 2.7mm Zinc: >245g/m²	Mesh diameter: 2.0mm Zinc: >215g/m²
2x1x1	Side wire diameter: 3.4mm Zinc: >265g/m²	Side wire diameter: 2.7mm Zinc: >245g/m²
3x1x1	Binding wire diameter: 2.7m	Binding wire diameter: 2.0m
