80mmX100mm Galvanized Gabion Wire Mesh Basket For Dam Protection

Büyük resim : 80mmX100mm Galvanized Gabion Wire Mesh Basket For Dam Protection

Ürün ayrıntıları:

Menşe yeri:	ÇİN
Marka adı:	KN
Sertifika:	CE, ISO, COC,BESC
Model numarası:	KNG01

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1000
Fiyat:	USD 14-19
Ambalaj bilgileri:	palet veya demet
Teslim süresi:	7
Ödeme koşulları:	L/C, Western Union, MoneyGram, T/T
Yetenek temini:	7 günde 1 40 metrelik kaplar

İletişim Şimdi konuşalım.

Detaylı ürün tanımı

Ürün adı:	20-30 yıl ömre dayanıklı 80mm x 100mm galvanizli gabion tel örgü sepet baraj koruması	Anahtar kelime:	Gabion teli ağ
Malzeme:	Galvanizli Demir Tel, Düşük Karbonlu Demir Tel, PVC TEL, GALFAN TEL	Delik şekli:	Altıgen, çift bükülme
Telli izleme:	2.4mm, 2.5mm, 2.7mm, 2.8mm, 3.05mm	Başvuru:	Gabions, kafesler, eğim koruması, çit örgüsü, inşaat teli ağ
Tip:	Altıgen tel örgü, çift bükülme	Açıklık:	80100mm, 100120mm, 60*80mm, vb.
Yüzey işleme:	Sıcak daldırılmış galvanizli, pvccoated, galvanizli+PVC kaplı	Ürün adı:	Gabion kutusu, Gabion kutusu tel örgü, gabion sepeti, sıcak satış 2x1x1m pvc kaplı ağır hizmet tipi
Boyut:	2m1m1m, 1x1x0.5m, 411m, 511, Özelleştirilmiş,	Özellik:	Kolay bir şekilde monte edilebilir, daha az taşıma yükü, güçlü ve dayanıklı, basit kurulum
Vurgulamak:	galvanized gabion wire mesh , Dam Protection Gabion Wire Mesh Basket , 80mmX100mm gabion wire mesh

80mmX100mm Galvanized Gabion Wire Mesh Basket For Dam Protection

20-30 Years Lifespan Durable 80mm X 100mm Galvanized Gabion Wire Mesh Basket for Dam Protection. Woven Gabion Wire Mesh produced from double-twisted hexagonal steel wire (4.7mm diameter, Zn-10%Al-MMO coating, 280g/m²) with 100x120mm apertures, this mesh forms modular units (2.4m x1m x0.5m) for riverbank armoring in high-sediment environments.

Key Features:

Reinforced edge binding (6.0mm wire) and horizontal cross-wires (4.5mm) spaced at 900mm intervals
Stabilizes 80-200mm fractured granite infill
Galvanized steel lacing pins (5mm) secure mesh joints
Integrated 80mm PVC drainage tubes at the base mitigate hydrostatic pressure
Complies with ASTM A975-21 for hydraulic structures
Optional zinc-aluminum alloy sacrificial anodes (ASTM B418) for saltwater interface zones
Open-weave design permits natural vegetation growth

Standard Gabion Basket Sizes:

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	1	0	1
2	1	1	1	2
3	1	1	2	3
4	1	1	3	4
5	1	1	4	5
6	1	1	5	6

Other sizes available as customized orders.

Standard Gabion Mattress Sizes:

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	0.3/0.5	0	0.3/0.5
2	1	0.3/0.5	1	0.6/1
3	1	0.3/0.5	2	0.9/1.5
4	1	0.3/0.5	3	1.2/2
5	2	0.3/0.5	4	3/5
6	2	0.3/0.5	5	3.6/6

Other sizes available as customized orders.

Product Applications:

Erosion Control: Stabilizes slopes and riverbanks, preventing soil erosion while allowing proper water drainage.
Retaining Walls: Constructs durable walls that secure hillside soil with a natural aesthetic.
Flood Protection: Forms barriers to divert water flow and reduce flood damage risk.
Coastal Defense: Stabilizes shorelines against wave action and erosion.
Road Embankments: Reinforces transportation routes by retaining soil and preventing landslides.
Bridge Construction: Strengthens abutments and foundations for structural integrity.

Technical Specifications:

Parameter	Description	Typical Value / Range
Material	Base material used for constructing the mesh	HDP/Galvanized Wire, PVC Wire
Coating	Surface treatment for enhanced corrosion resistance	Galvanized, HDP Galvanized, PVC Coated
Wire Diameter	The thickness of the wires used in the mesh	Mesh Wire: 2.0~3.05mm Selvage Wire: 2.4~4.0mm Tie Wire: 2.0~2.4mm
Mesh Opening Size	The size of the openings between wires	6080mm, 80100mm, 100120mm, 120150mm
Overall Dimensions	Standard Gabion Roll and Gabion Basket Size	Gabion Roll Width: 1~4m Gabion Basket: 111m, 211m, 311m, 411m, 511m, 611m
Lifespan	Expected service life	Generally 6~20 years, depends on environment
